Red Devil River. The cable may be ordered with the 12 pin connector shown here, the 94 & 95 16 pin connector, or with universal bare pins. 12 Pin versions have built in the 10K ohm resistor required by some ECMs. The resistor can also be switched off if needed. USB to ALDL Cable comes with 5' USB extension cable, and Driver/Software CD. Apr 22, 2010 - Here is a Link to a place that sells discount ALDL cables so you can hook up your OBD I or OBD II car to a. Driver software for our USB cables.

About WinALDL is software to datalog on GM vehicles that use the old 160 baud rate. This includes but is not limited to vehicles using a 1227747 and 1227165 ECM. Most older TBI GM computers will speak this protocol. WinALDL does NOT speak to newer GM OBD1 vehicles that use 8192 baud communication. WinALDL is available from WinALDL was written several years ago. It will work best on Windows XP or older operating systems, if available. You may need to use a VM or Windows XP compatibility mode on newer Windows7 systems in order for it to run 100% properly.

WinALDL will work with both our ALDU1 and AutoProm. Setup There are a few setup tasks that need to be performed. • Ensure that your ALDU1 or AutoProm is assigned a COM port between 1 and 4. Make sure you choose a port that does not conflict with system resources.

(see ) • If you are using the AutoProm, ensure that it is set to pass-through *NOT* AutoProm mode. (see ) • On most 160 baud applications, you will need to set the switch to 10k mode on your AutoProm or ALDU1 • Set the COM port selection in WinALDL to match what it set up to on the USB driver under the control panel.

• Set the baud rate to 4800 within the WinALDL program. • Select the ECM type in WinALDL which matches your ECM. • Make sure the ALDU1 is connected to the laptop prior to starting the software. • Turn your key off, connect the ALDU1 to the car, and start the software. • Turn the car on, it should connect.
